Products
AICERY focuses on providing refrigeration system unit with over 20 years of experience
BITZER
Product category:
Piston compressor condensing unit
Product description:
Key word:
Tel:
E-mail:
BITZER
| 机组型号 Unit Model |
压缩机型号 Com.Model ( Bitzer) |
冷凝温度 Condensing Temp.(℃) |
制冷量 输入功率 Qo[Kw] Pe[Kw] Cooling Capacity Input Power |
|||||||||
| 蒸发温度 Evaporation Temp.(℃) | ||||||||||||
| -15 | -10 | -5 | 0 | 5 | ||||||||
| Qo | Pe | Qo | Pe | Qo | Pe | Qo | Pe | Qo | Pe | |||
| EPB-FF-3HYS | D3-15.1Y (3HP) |
40 | 6.8 | 3.5 | 8.4 | 3.8 | 10.1 | 4.1 | 12.2 | 4.2 | 14.5 | 4.3 |
| 45 | 6.2 | 3.7 | 7.6 | 4.0 | 9.2 | 4.3 | 11.1 | 4.6 | 13.2 | 4.7 | ||
| EPB-FF-5HYS | D4-16.1Y (5HP) |
40 | 7.4 | 3.7 | 9.1 | 4.0 | 11.2 | 4.3 | 13.5 | 4.5 | 16.1 | 4.7 |
| 45 | 6.8 | 3.8 | 8.4 | 4.2 | 10.2 | 4.5 | 12.3 | 4.8 | 14.8 | 5.1 | ||
| EPB-FF-7HYS | Q7-28.1Y (7HP) |
40 | 12.6 | 5.8 | 15.5 | 6.3 | 18.9 | 6.7 | 22.7 | 7.1 | 27.1 | 7.5 |
| 45 | 11.4 | 6.1 | 14.1 | 6.6 | 17.1 | 7.1 | 20.7 | 7.6 | 24.2 | 8.1 | ||
| EPB-FF-9HYS | Q7-33.1Y (9HP) |
40 | 14.5 | 6.7 | 17.9 | 7.3 | 21.8 | 7.9 | 26.2 | 8.4 | 31.4 | 8.8 |
| 45 | 13.2 | 7.0 | 16.2 | 7.7 | 19.8 | 8.3 | 23.9 | 8.9 | 28.5 | 9.5 | ||
| EPB-FF-12HYS | S12-42Y (12HP) |
40 | 17.6 | 7.6 | 21.9 | 8.4 | 26.9 | 9.9 | 32.6 | 9.8 | 39.0 | 10.3 |
| 45 | 15.8 | 7.8 | 19.8 | 8.7 | 24.3 | 9.6 | 29.6 | 10.4 | 35.6 | 11.1 | ||
| EPB-FF-15HYS | S15-52Y (15HP) |
40 | 23.7 | 10.2 | 29.0 | 11.1 | 35.1 | 11.9 | 42.1 | 12.6 | 50.3 | 13.1 |
| 45 | 21.7 | 10.7 | 26.5 | 11.7 | 32.1 | 12.7 | 38.6 | 13.6 | 46.0 | 14.3 | ||
| EPB-FF-20HYS | S20-56Y (20HP) |
40 | 26.2 | 11.2 | 31.9 | 12.3 | 38.6 | 13.3 | 46.3 | 14.1 | 55.2 | 14.5 |
| 45 | 23.9 | 11.7 | 29.2 | 12.9 | 35.4 | 14.1 | 42.4 | 15.1 | 50.6 | 16.0 | ||
| EPB-FF-25HYS | V25-71Y (25HP) |
40 | 31.0 | 14.0 | 38.6 | 15.4 | 47.3 | 16.6 | 57.5 | 17.7 | 69.1 | 18.6 |
| 45 | 27.9 | 14.5 | 34.8 | 16.0 | 42.8 | 17.4 | 52.1 | 18.6 | 62.8 | 19.8 | ||
| EPB-FF-30HYS | V30-84Y (30HP) |
40 | 37.6 | 16.7 | 46.6 | 18.2 | 56.9 | 19.6 | 68.9 | 20.7 | 82.4 | 21.6 |
| 45 | 34.0 | 17.4 | 42.2 | 19.1 | 51.7 | 20.7 | 62.7 | 22.1 | 75.2 | 23.2 | ||
| EPB-FF-35HYS | Z35-106Y (35HP) |
40 | 47.5 | 20.1 | 59.0 | 22.0 | 72.4 | 23.6 | 87.8 | 25.1 | 105.4 | 26.2 |
| 45 | 42.9 | 20.9 | 53.3 | 23.1 | 65.5 | 25.8 | 79.6 | 26.9 | 95.8 | 28.4 | ||
| EPB-FF-40HYS | Z40-126Y (40HP) |
40 | 55.3 | 23.8 | 68.9 | 26.1 | 84.6 | 28.1 | 102.2 | 29.9 | 123.2 | 31.3 |
| 45 | 49.8 | 24.5 | 62.1 | 27.1 | 76.5 | 29.6 | 93.0 | 31.7 | 112.0 | 33.6 | ||
| EPB-FF-50HYS | Z50-154Y (50HP) |
40 | 67.7 | 29.6 | 84.0 | 32.7 | 102.8 | 35.5 | 124.4 | 38.1 | 148.9 | 40.3 |
| 45 | 61.1 | 30.6 | 76.1 | 34.0 | 93.3 | 37.3 | 113.2 | 40.4 | 135.8 | 43.1 | ||
| 机组型号 Unit Model |
压缩机型号 Com.Model ( Bitzer) |
冷凝温度 Condensing Temp.(℃) |
制冷量 输入功率 Qo[Kw] Pe[Kw] Cooling Capacity Input Power |
|||||||||
| 蒸发温度 Evaporation Temp.(℃) | ||||||||||||
| -20 | -25 | -30 | -35 | -40 | ||||||||
| Qo | Pe | Qo | Pe | Qo | Pe | Qo | Pe | Qo | Pe | |||
| EPB-FF-3LYS | Q4-24.1Y (3HP) |
40 | 8.7 | 4.2 | 6.3 | 3.7 | 4.8 | 3.2 | 3.5 | 2.7 | 2.4 | 2.3 |
| 45 | 7.2 | 4.4 | 5.6 | 3.8 | 4.2 | 3.3 | 30.6 | 2.8 | 2.1 | 2.3 | ||
| EPB-FF-4LYS | Q5-25.1Y (4HP) |
40 | 8.5 | 4.5 | 6.6 | 4.0 | 5.1 | 3.5 | 3.7 | 2.9 | 2.6 | 2.4 |
| 45 | 7.7 | 4.6 | 6.0 | 4.1 | 4.5 | 3.5 | 3.3 | 2.9 | 2.2 | 2.3 | ||
| EPB-FF-5LYS | Q5-28.1Y (5HP) |
40 | 9.9 | 5.2 | 7.8 | 4.6 | 5.6 | 4.0 | 4.4 | 3.4 | 3.2 | 2.8 |
| 45 | 8.9 | 5.4 | 7.0 | 4.7 | 5.3 | 4.1 | 3.9 | 3.4 | 2.8 | 2.8 | ||
| EPB-FF-6LYS | Q5-33.1Y (6HP) |
40 | 11.6 | 6.2 | 9.3 | 5.5 | 7.2 | 4.8 | 5.5 | 4.1 | 4.1 | 3.4 |
| 45 | 10.5 | 6.5 | 8.4 | 5.7 | 6.5 | 4.9 | 5.0 | 4.1 | 3.6 | 3.5 | ||
| EPB-FF-8LYS | S8-42Y (8HP) |
40 | 15.3 | 7.5 | 12.1 | 6.6 | 9.3 | 5.7 | 4.8 | 3.9 | 3.0 | 3.1 |
| 45 | 13.8 | 7.7 | 10.8 | 6.8 | 8.3 | 5.8 | 6.0 | 4.8 | 4.1 | 3.9 | ||
| EPB-FF-10LYS | S10-52Y (10HP) |
40 | 18.8 | 9.5 | 15.1 | 8.4 | 11.9 | 7.3 | 9.1 | 6.2 | 6.7 | 5.2 |
| 45 | 17.1 | 10.0 | 13.7 | 8.7 | 10.8 | 7.5 | 8.2 | 6.4 | 5.8 | 5.3 | ||
| EPB-FF-12LYS | S15-56Y (12HP) |
40 | 20.9 | 10.2 | 16.7 | 9.0 | 13.1 | 7.9 | 9.9 | 6.7 | 7.1 | 5.6 |
| 45 | 19.0 | 10.1 | 15.1 | 9.3 | 11.8 | 8.0 | 8.8 | 6.8 | 6.1 | 5.7 | ||
| EPB-FF-15LYS | V15-71Y (15HP) |
40 | 25.6 | 13.3 | 20.5 | 11.7 | 16.1 | 10.1 | 12.3 | 8.5 | 8.8 | 7.0 |
| 45 | 23.3 | 13.8 | 18.6 | 12.0 | 14.5 | 10.3 | 10.9 | 8.6 | 7.5 | 7.0 | ||
| EPB-FF-20LYS | V20-84Y (20HP) |
40 | 29.6 | 15.2 | 23.3 | 13.4 | 18.0 | 11.6 | 13.5 | 9.8 | 9.8 | 8.2 |
| 45 | 26.5 | 15.6 | 20.9 | 13.7 | 16.1 | 11.7 | 12.1 | 9.9 | 8.7 | 8.1 | ||
| EPB-FF-25LYS | Z25-106Y (25HP) |
40 | 38.1 | 19.9 | 29.7 | 17.4 | 22.5 | 15.0 | 16.5 | 12.7 | 11.6 | 10.6 |
| 45 | 34.3 | 20.4 | 26.6 | 17.8 | 20.1 | 15.3 | 14.7 | 12.8 | 10.2 | 10.6 | ||
| EPB-FF-30LYS | Z30-126Y (30HP) |
40 | 44.1 | 21.8 | 34.5 | 19.3 | 26.3 | 16.7 | 19.5 | 14.2 | 13.8 | 11.8 |
| 45 | 39.6 | 22.5 | 30.9 | 19.8 | 23.5 | 17.0 | 17.3 | 14.3 | 12.1 | 11.8 | ||
| EPB-FF-40LYS | Z40-154Y (40HP) |
40 | 56.7 | 28.6 | 45.6 | 25.2 | 36.0 | 22.0 | 27.4 | 18.6 | 19.6 | 15.5 |
| 45 | 51.7 | 29.8 | 41.4 | 26.1 | 32.4 | 22.5 | 24.3 | 18.9 | 16.7 | 15.6 | ||
