Inlet Pressure Regulating Valve — Suit for all refrigerants and ammonia

Product category:

Valve series

Product description:

Key word:

Valve pressure regulating valve

Tel:

E-mail:

Inlet Pressure Regulating Valve — Suit for all refrigerants and ammonia

Technical Parameters:

* Design pressure: 6.4MPa

* Strength Test Pressure: 6.0MPa

* Opening Pressure Adjustment Range:

Type A

Adjustment range: 0~10bar Factory setting: 3bar

Type D

Adjustment range: 5~20bar Factory setting: 10bar

* Application Area:

a. Hot gas defrosting system

b. Heat recovery system

c. Evaporator pressure regulating

d. Condenser pressure regulating

e. Screw compressor oil pressure regulating

f. All inlets pressure regulating

* Applicable Temperature Range: -46℃ ~ +150℃

* Working Mode: The valve opens when the inlet pressure rises to the set value. The valve closes when the inlet pressure is lower than the set value.

* Opening Mode: With a manual opening device

* Applicable Media: R22、R507、R407C、R404A、R134a、R410A、R717、ammonia and other refrigerants and frozen oil.
